• (1+1), (1+3), (1+4) and (1+6) Bobbin type.
  • Material to be stranded:- Aluminium, Aluminium Alloy, Copper and Cores. Wire Size 1.5 to 4mm, Core Size upto 20 mm .
  • Bobbin Size:-630, 800, 1250, 1600 mm DIN.
  • High production rate at low cost.
  • Light weight & low noise.
  • Operator friendly loading & unloading of Bobbin.
  • Insulated core laying is also possible.
  • Hardened Pintle type Bobbin holding.
  • Band Brake type Bobbin Tension.
  • Pneumatic Disc brake.
  • Quick closing/releasing, Spring loaded Die holder with longitudinal adjustment.
  • Lay length by Gear Box (Lay changing by change gear) or Multi speed gearbox; driven by line shaft or Infinity lay length by separate Geared- motor with PLC control.
  • Dual capstan type Haul-off unit.
  • Pintle type/shaft type Take-up with motorised lowering/lifting arrangement.
  • Telescopic type safety guard .
  • Max. Machine Speed: - 1000 rpm.
